SDM630 DMR MOBILE RADIO
DESCRIPTION
The SDM630 advanced control head provides for extended applications and messaging at the user’s fingertips. Designed to push instant messaging, dispatch, telemetry and control applications out to the mobile user, this radio expands their abilities beyond voice communications. The full keypad enables enhanced dialling, giving access to any radio, group or further to telephone networks. Other features include full text message composition, 12 additional programmable keys with press ‘n’ hold.
KEY FEATURES
SDM600 Range
- 1 W to 25 W output power
- Quick mount bracket available
- IP54 ingress protection
- Connectors placed for ease of installation
- 100 (SDM610), 2000 (SDM622 and SDM630) channels
- Status and Short Data/Text Messaging, compliant with ETSI standards
SDM610 Control Microphone
- 4 programmable buttons
- Clear 6 character display
- IP54 ingress protection
- Bracket for easy mounting
- Ergonomic design
- Dedicated emergency button SDM622 Controller Microphone
- Multi-line graphic display
- 12 button alphanumeric keypad
- 6 programmable buttons
- IP54 ingress protection
- Volume Up/Down controls
- Dedicated emergency button
SDM630 Control Head
- Intuitive menu-based interface
- Large clear 5-line display
- IP54 ingress protection
- 11 programmable direct function buttons
- Full dial pad
- 2 call buttons
- Dedicated emergency button
HOW IT WORKS
Available for DMR Tier II conventional, DMR Tier III trunked and analogue modes of operation, SIMOCO Xd mobiles combine digital voice and data with flexible vehicle installation options. Digital voice clarity, instant text and status messaging are a core part of this digital system.
Standard Package Includes:
- Radio transceiver
- Microphone or Control Head
- Loudspeaker
- Microphone hanging bracket
- Fused power cable
- Quick reference guide
- 2-Year standard warranty
TECHNICAL SPECIFICATIONS
Frequency Bands:
VHF:136–174MHz
UHF:400–480MHz
UHF:440–520MHz
Dimensions (transceiver only):
152 x 48 x 212 mm
Power Supply:
10.8 – 16.3VDC
Standby Power Consumption:
3W
Receive Only Power Consumption
16W (4W audio output)
Transmit Power Consumption:
82W (25W RF)
Frequency Stability:
0.5ppm
Channel Bandwidth:
12.5/25kHz
Channel Capacity:
100 (SDM610), 2000 (SDM630)
Weight:
1.2 kg
Emission Masks:
7K60FXD (data), 7K60FXE (voice), 7K60F1W (voice and data) for 4FSK digital modulation, 11K0F3E for 12.5 kHz modulation
1 – 25W
Modulation Limiting:
+/-2.5 @ 12.5kHz, +/-5.0 kHz @ 25kHz
FM Hum and Noise:
40dB (TIA-603-B)
Conducted / Radiated Emission:
Complies with ETS086-1 / ASNZS4295 / TIA603-B
Adjacent Channel Power:
-60dBc (ETS086-1)
Audio Response:
+1/-3dB
Audio Distortion:
4% @ 4W
Digital Vocoder Type:
AMBE+2
Analogue Sensitivity:
-117.5dBm (12dB SINAD)
Digital Sensitivity:
-117.5dBm (BER 1%)
Intermodulation:
65dB (70dB typ. ETS086-1)
Adjacent Channel Selectivity:
65dB (ETS086-1)
Spurious Rejection
70dB (ETS086-1)
Hum and Noise:
40dB (TIA603-B)
Audio Response:
+1/-2dB (0.3-2.55kHz analogue)
Audio Distortion:
5% @ 4W Analogue Mode
Conducted Spurious Emission:
-57dBm (ETS086-1)
-30°C to +60°C
Storage Temperature:
-40°C to +80°C
IP Rating / Humidity:
IP54
