SDP660 DMR PORTABLE RADIO
DESCRIPTION
Offering full keypad functionality for telephone, complex group calls, advanced data messaging and a total of 12 programmable function keys, the SDP660 is ideally suited to organisations with complex operation needs.
- Multiple programmable buttons, from side function keys to main keypad for ultimate customisation
- Intuitive keypad
- Full colour display with intuitive interface
KEY FEATURES
- Multiple programmable buttons, from side function keys to main keypad for ultimate customisation
- Intuitive keypad
- Full colour display with intuitive interface
- Control Channel Hibernation to enable solar powered sites
- Tx Interrupt to allow instantaneous correction of old or incorrect information
- Integrated Man Down and lone worker – motion and positional sensor for full employee safety
- In-radio Geofencing
- Group Presence Checking to increase the capacity of systems
- AES256 Encryption for protection against eavesdropping
- Dynamic Group Number Assignment to create and remove talkgroups on the fly
- IP67 protection from water and dust ingress
- Ear-piece speaker for full duplex calling mode
- Integral GPS Antenna for dedicated satellite performance placed optimally within the radio
- High output main speaker for loud & clear digital audio
- Multi-colour LED for clear indication of radio status
- Easy access to emergency button for no-doubt notification
- Ergonomic push to talk
- Selector knob enhances use ability, for control of volume and brings smartphone speed scrolling to the radio
- IP67 rated side connector
- Battery life 40% greater than equivalent analogue and FDMA technologies
- Full Duplex Telephony to allow more natural, flowing conversations and a seamless integration with phone-based users
- MPT1327 to enable terminal-led migration
- OTAP to allow remote fleet management
HOW IT WORKS
Available for DMR Tier II conventional, DMR Tier III trunked and analogue modes of operation, the SDP660 Advanced offers a rich feature set and improved hardware modifications to the antenna, PTT, battery and keypad.
TECHNICAL SPECIFICATIONS
Frequency Bands:
VHF:136–174MHz
UHF:400–480MHz
UHF:440–520MHz
Channel Capacity:
2000
Channel Bandwidth:
12.5/25kHz
Dimensions:
137 x 64 x 36 mm
Weight (with standard battery):
199g (transceiver)
141g (standard battery)
Battery Life (with standard battery):
12 hours
Power Supply:
7.2V DC nominal
Frequency Stability:
± 2ppm
Emission Masks:
7K60FXD (data), 7K60FXE (voice), 7K60F1W (voice and data) for 4FSK digital modulation, 11K0F3E for 12.5 kHz modulation
5 W programmable (5 W RF power 400-470 MHz, 4 W RF power 470-480 MHz.)
Modulation Limiting:
+/-2.5 @ 12.5 kHz, +/-5.0 kHz @ 25 kHz
FM Hum and Noise:
40dB (TIA-603-B)
Conducted / Radiated Emission:
-36dBm
-60dBc @12.5kHz
Audio Response
+1/-3dB
Audio Distortion
3% (TIA-603-B)
Digital Vocoder type
AMBE+2
-117.5dBm (12dB SINAD)
Digital Sensitivity:
-117.5 dBm (1% BER)
Intermodulation:
65dB (ETS086-1)
Adjacent Channel Selectivity:
60dB @12.5kHz (ETS086-1)
Spurious Rejection:
70dB (ETS086-1)
Hum and Noise:
40dB (TIA603-B)
Audio Response::
+1/-2dB (0.3-2.55kHz)
Conducted Spurious Emission:
-57dBm
Operating Temperature:
-30 – +60ºC
Storage Temperature:
-40 – +80ºC
IP Rating / Humidity IP54:
IP67 (IEC60529)
GPS:
L1, TTFF < 60s
